Tachometer PCE-DT 65

Order no.: PCE-DT 65

Brand: PCE INSTRUMENTS

Description/Highlights

PCE-DT 65 is a digital handheld tachometer, or rotation meter, that can take both contact and non-contact measurements of rotation speed and linear speed. This handheld tachometer features an integrated laser and includes a mechanical attachment with contact probes, making it the ideal measuring instrument for machines, motors, conveyor belts and other moving parts. Non-contact measurements are taken with the help of laser-reflective tape that is fixed on the moving part. Contact measurements are taken using the included mechanical attachment and contact probes.
- Speed measurement: rpm
- Surface velocity: m/min
- Number of rotations: counter
- Frequency: m, in, ft, yd
- Linear measurement: m, in, ft, yd

PCE-DT 65 comes factory calibrated.

Specification

- Measurement range, laser-optics: 2 … 99,999 rpm
- Measurement range, mechanical: 2 … 20,000 rpm
- Resolution:
+ 0.1 rpm in the range of 2.0 … 9999.9 rpm
+ 1 rpm in the range of 10,000 … 99,999 rpm
- Accuracy: ± 0.05% of rpm value ± 1 digit
- Measuring distance: 50 … 500 mm / 1.96 ... 19.68 in
- Memory: 10 measurement values
- Power supply: 1 x 9V block / 6V external power supply
- Operating temperature range: 0 … 50°C / 32 ... 122°F
- Casing: ABS plastic
- LCD display: 5 digits, 22 mm / 0.9 in height
- Dimensions: 160 x 60 x 42 mm / 6.24 x 2.36 x 1.65 in
- Weight: 200 g / < 1 lb

Delivery Scope

1 x PCE-DT 65 tachometer
1 x Mechanical attachment
1 x Adapter wheel
1 x Measuring probe (outer cone)
1 x Measuring hollow point (inside cone)
1 x Belt bag
1 x Battery
3 x Stripes reflective tape (each 20 mm or 0.78 in)
1 x User manual
